Battioni FAN530, 525 CFM


Battioni FAN530, 525 CFM
Item Number: FAN530
Size/Color
Quantity


Battioni FAN420, 525 CFM (Counterclockwise)

*Must be shipped via Freight!* See our Freight Terms and Conditions HERE

The cooling for FAN Pumps is provided by fresh air forced by high efficiency cooling fans. An accurate study of the aluminum conveyor, the body fins profile and inlet and outlet port make the pump suitable for heavy duty applications.

The FAN features the Crash Protection System: sliding flanges protection mechanism that prevents the housing or rotor from breaking in case of blades crash. The pump is easily repairable inexpensively in field. The FAN pump can be equipped with the latest automatic air injection cooling system to enable continuous operation at 91% range of vacuum.

Details:

  • • Long life blades
  • • Crash protection system
  • • Automatic lubrication
  • • External side oil tank
  • • Predisposition integrated air filter
  • • 4-ways valve, poppet check valve
  • • Air injection cooling
  • • Available in counterclockwise rotation
Specifications:
Max rate of flow, (CFM)
525
Max rpm, (rpm) 1500
Max working pressure, Bar (PSI) 2.5 (36)
Max vacuum %, InHg 95% (28.5")
Power @ max vacuum, kW (hp) 27 (36.1)
Net weight, Kg (lbs.) 223 (492)
Available hoses connections Ψ 76 mm (3”) / Ψ 80 mm / Ψ 100 mm (4”)
Downloadable Manuals and Files - FAN Technical Data
